KEY FEATURES:

• Custom Designed And Manufactured Bakelite VU Meters With Traditional Ballistics

• Custom Designed Hand Wound Input & Output Transformers Hermetically Potted in MuMetal Casing

• Class A Operation Throughout The Signal Chain

• Up to 80dB Of Gain

• Channel Strip Design With MIC IN, LINE IN/OUT, DI, And Effect Inserts

• Low Noise Design Topology

• Custom Manufactured GR Style Bakelite Knobs From Original Moulds

• New Old Stock Matched Valves For Each Unit Manufactured

• Switchcraft® & Neutrik® Audio Connectors

• Active True Bypassable FILTER Section Featuring 4 Useful HPF & LPF Filter Frequencies of 50Hz, 150Hz, 5kHz, 2kHz @ −6 dB per octave (−20 dB per decade) Butterworth 1st order.

• Internal Switch To Toggle Between ECC82 Or Premium Grade 6350 ★★★★★ Output Tube *See Options Below

• Metal Film Resistors, Foil & Film Capacitors, Rubycon® & NIPPON Chemi-Con® Elcos Throughout The Unit

• All Through-hole Components And No SMDs

• Japanese Made TOCOS® Sealed Potentiometers

• Carling Toggle Switches

• Modular Design Throughout The Unit

• 4mm Thick Carbon Steel Face Plates

• Fully Regulated Solid-State Power Supply With Soft Start & Short Circuit Protection On All Nodes

• High-Quality Sealed Japanese Relays With Gold Contacts For All Localized Signal Switching

• Individual Anti Pop Soft Start & Stop Phantom Power Switching & Indicator Lamp Per Channel

• Buffered & Isolated VU Meter Driver Circuit With Selectable +4dB Or +8dB Range

• Saturation THD Indicator Of The Input Valve

• 86V to 260VAC Global Line Operation.
