Specifications
Self Noise A-weighted: -102 dB (at 0dB IN/OUT setting)
THD+N absolute: 0.026% (1V RMS, 1 kHz at max gain reduction)
Frequency Response: 20Hz - 30kHz (+/- 0.3dB)
Max Input Level: +22dBV
Max Output Level: +28dBV
Input XLR balanced, impedance 10 kOhm
Output XLR balanced, impedance 75 Ohm
AC Powering (internally switchable 240V/120V) 50/60Hz
Power Consumption: max. 70 Watt
Weight: 9.4kg (11.6kg shipping)
Dimensions:
LAAL (3U) Width: 484mm (incl. sockets)
Height: 144,5mm
Depth: 118mm
Shipping Width: 123,5mm
box Height: 154mm
Depth: 55mm (with knobs)
Package contains: - LAAL limiter
- Custom shielded AC cord
