With one oscillator, a sub oscillator and a filter that both whispers and screams. This piece of machinery have been meticulously crafted and assembled in a high tech cave in the heart of Malmö.

SWENIGISER SPECIFICATIONS

• 1.5 mm rigid stainless steel casing.
• Front 3.5 mm cv jacks and one 6.3 mm main output.
• Powered by 9-18V center positive adapter, 300mA or more.
• Direct OUT 6.3mm jack, on the back.
• Power switch
• Power on LED indicator
• Midi to CV converter

1 x VCO sine, tri, square, pwm, saw variable
SLIDE
VCO MOD BUSS
VCO PWM/SAW SHAPE BUSS

1 x VCF, 15 modes
CUTOFF
RESONANCE
TRACKING
VCF VOL/DRIVE

1 x VCA
VCA VOL/DRIVE
VCA OFFSET
VCA ENV BUSS
VCA LFO BUSS

1 x SUB OSC VOL

1 x LFO
LFO SPEED
LFO SHAPE (TRI/SAW)

3 x ENV
ENV 1: A, D
ENV 2: A, R
ENV 3: A, D, S, R

EXPANSION

• Midi section: 4xCV out, 3x gate out, 3x gate booster in
• CV expander section, buffered in/out
• CV out (SIN,TRI, SQR, PWM, SAW, LFO TRI, LFO SQR, ENV 1-3)
• CV in (ENV EXT 1-2, LFO EXT 1-3, VCO SHAPE, VCO FM+attenuator, VCF INV
• Audio input: VCF (pre volume/drive), VCA+attenuator
• CV levels converted to Eurorack standards.
• Main output
• White noise out

Included in the box:
1 x SWEnigiser
1 x Power supply 12V EU-Standard
2 x 30cm patch cables
